Previously PBI Height Safety

Kattsafe Ladder Support Bracket

A ladder support bracket provides a secure attachment point for portable ladders preventing movement in any direction – ensuring user safety.

PBI_Logo_Asset_45_x_75_px-1

Specs & Details

  • Key features
  • Technical Information

Using a three-piece profiled plate construction the slotted locking device allows on-site adjustment providing both pitch and angle variation of the ladder support ensuring maximum stability and safety of the user.

HOW IT IS USED

Positioned on the edge of the roof with rung support protruding the gutter edge or fixed to the external face to allow supportive attachment.

HOW IT WORKS

The ladder rests on the ladder tie-off flange and not the gutter or fascia. The kattsafe ladder support bracket can be fixed to various surfaces and has a working load limited of 120kg.

PERFORMANCE

Katt ladder support brackets conform to AS 1651:2018 fixed platforms, walkways, stairways, and ladders, design, construction and installation.



INSTALLATION

Support structure integrity, suitability, and fixing method to be assessed and determined by a competant person prior to installation.

MAINTENANCE

Visual inspection for any damage or loose fixings must be done periodically and prior to installation. No certified maintenance is required. Basic wear and tear preventative maintenance is recommended as per the manufacturer's specifications and recommendations.

WARRANTY

10 years from the date of purchase subject to correct installation, use, and maintenance in accordance with the manufacturer's specifications and recommendations. Excludes powder coating.

PBI_Logo_Asset_45_x_75_px-1

Projects

Specific to product

Cotton & Laby Buildings - VUW

Cotton & Laby Buildings - VUW

Architect: N/A

Contractor: LT McGuinness

Location: Wellington


  • Solution

    Fall Arrest Anchors, RoofSafe Cable, Vertical Access

  • Scope Requirements

    Fall Arrest

Project Kelly - Auckland

Project Kelly - Auckland

Architect: Ignite Architects

Contractor: Haydn & Rollett

Location: Auckland


  • Solution

    RoofSafe Cable, Fall Arrest Anchor Points

  • Scope Requirements

    Fall Arrest, Fall Protection

Te Kairanga Winery - The RunHolder - Martinborough

Te Kairanga Winery - The RunHolder - Martinborough

Architect: Nott Architects

Contractor: Holmes Construction

Location: Martinborough, Wellington Region


  • Solution

    Fall Arrest Anchors, Ladder Brackets

  • Scope Requirements

    Fall Arrest, Roof Access

Victoria Lane Apartments Wellington

Victoria Lane Apartments Wellington

Architect: Athfield Architects Limited

Contractor: LT McGuinness

Location: Wellington


  • Solution

    Fall Arrest Anchors, Altrac Abseil Rail System, Altrac Trolleys

  • Scope Requirements

    Fall & Abseil Access, Facade Access

Woolworths (formerly Countdown) Dunedin

Woolworths (formerly Countdown) Dunedin

Architect: N/A

Contractor: Stride Property Limited

Location: Dunedin, New Zealand


  • Solution

    Walkway Systens, Guardrail Systems, Skylight Safety Mesh Systems

  • Scope Requirements

    Fall Arrest, Fall Restraint

Thermosash Project

Thermosash Project

Architect: Create Architects and Engineers

Contractor: Thermosash

Location: Levin, New Zealand


  • Solution

    3M Cable Fall Arrest System

  • Scope Requirements

    Fall Arrest

Te Kura Whakatipu O Kawarau

Te Kura Whakatipu O Kawarau

Architect: Stephenson & Turner Architects

Contractor: Southbase Construction

Location: Queenstown, New Zealand


  • Solution

    3M Roofsafe Surface Mounted Cable Static Line

  • Scope Requirements

    Fall Arrest

Toll New Zealand

Toll New Zealand

Architect: Williams Architects

Contractor: Watts Group

Location: Auckland, New Zealand


  • Solution

    3M RoofSafe Cable

  • Scope Requirements

    Fall Arrest

Manukau Bus & Train Interchange

Manukau Bus & Train Interchange

Architect: Cox Architecture

Contractor: NZ Strong

Location: Auckland, New Zealand


  • Solution

    Kingspan Safepro2 Cable Static Lifeline

  • Scope Requirements

    Fall Arrest

Wanaka Recreational Centre

Wanaka Recreational Centre

Architect: Warren & Mahoney

Contractor: Cook Brothers Construction

Location: Wanaka, New Zealand


  • Solution

    Safepro2 Cable, 3M Fall Arrest Anchors

  • Scope Requirements

    Fall Arrest
